Product Details:
|
| Product Name: | Ethernet Transceiver | Frequency: | 700MHz (can Be Customized 300-3300MHz) |
|---|---|---|---|
| Working Voltage: | DC28V (AC110-240V) | RF Power: | 50dBm (100W) |
| Encryption: | AES 128/256 Bits | Serial Port: | RS232/RS485 Serial Port |
| Highlight: | FDD IP Transceiver,700MHz IP Transceiver,50dBm COFDM IP Transmitter |
||
Outdoor Long Range Wireless IP Transceiver with Control System Audio Video
IP video transceiver Specifications:
| Model | KP-FDD100W |
| Working voltage | DC28V (AC110-240V) |
| Working current | 14.5A/28V |
| TX output frequency | 700MHz (can be customized 300-3300MHz),step in 1MHz |
| RX output frequency | 400MHz (can be customized 300-3300MHz),step in 1MHz |
| RF bandwidth | 1/2/4/8MHz |
| RF power output | 50dBm (100W) |
| Encryption/decryption mode | AES128 bits(user-defined password) |
| Modulation | FDD-COFDM 2K |
| Transfer rate | 2x30 Mbit/s uplink and downlink |
| RF connector | N type *2 |
| Ethernet | Standard RJ45 port *2 |
| Serial port | RS232/RS485 serial port |
| Baud rate | 115200bps maximum |
| Two way audio | Aviation plug |
| LCD panel with keypad | Easy to set the related parameters |
| Dimension | 575*505*360mm |
| Weight | 26kg |
| Transmit distance | 30-50km NLOS /50-100km LOS |
Shockproof Digital Transceiver Description:
KP-FDD100W is a new COFDM digital transmitter receiver with Frequency-division duplexing (FDD) technology, designed with dual-mode rf transceiver architecture and system which operate at different carrier frequencies ideal for long range communication in network solution. The FDD technique uses different frequency bands for send and receive operations, the sending and receiving data signals don't interfere with each other that is suprior to Time Division Duplex (TDD) for symmetric traffic such as voice applications in broadband wireless networks.
KP-FDD100W transceiver is implement of transparent IP ethernet interface that able balance and stable high-speed data rate with 30Mbit/s each for uplink and downlink.Highly integrated with Network/modulator& demodulator and full-band rf output all-in-one,which is ideal for Broadcasting,public security system,emergency system,Police,military and ect required for long distance wireless network links.
Feature:
FAQ:
Q1: What can I buy from you?
COFDM digital AV transmitter, IP mesh radio, analog video transmitter, radio data transceiver, and transmitter receiver OEM main board.
Q2: Why should I choose you?
Our core R&D team comes from the first-class university in China, major in communication engineering. We believe that wireless communication will keep on developing in professional markets in the future.
Q3: Do you have a minimum order quantity?
No MOQ limit, 1pc is acceptable.
Q4: What kind of product service can I have?
OEM & ODM service.
Q5: What is the product warranty?
We offer two-year-warranty and lifelong maintenance.
Q6: What is the average lead time?
5-7 working days for regular model, and 20-30 working days for customized model.
Q7: What kinds of payment methods do you accept?
We accept bank transfer, Western Union, PayPal, or cash payment.
Q8: Can you supply the relevant documentation?
Yes, we can provide most documentation including Certificates of Analysis / Conformance; Country of Origin, and other export documents where required.
