Product Details:
|
| Name: | Omni Antenna | Frequency: | 806~960MHz |
|---|---|---|---|
| Gain: | 10dBi | Bandwidth: | 70MHz |
| Vertical Beamwidth: | 8° | Dimension: | 1.8m |
| High Light: | 800MHz Wireless RF Antenna,10dbi Wireless RF Antenna,1.8m Wireless RF Omni Antenna |
||
800MHz 10dbi Wireless RF Omni Antenna GSM / CDMA Whip Antenna 1.8m
The KP-OM800C10 is a high gain UHF log periodic antenna ideal for base station or in-building applications with a constant perfomance throughout the band. It's with 10 dBi gain over 470-862 MHz frequency range. Log periodic dipole array design includes installed N-Female (Jack) connector
Application:
Image, video, data transmission
Point to mult-point system
Lora RFID systems
Features:
High gain Low VSWR
Long rang distance transimission
Fiberglass material
Pole mounting steel
Point to point; point to multi-point application
Specification:
| Category | Fiberglass Antennas |
| Frequency Range | 806~960MHz |
| Bandwidth | 70MHz |
| Gain | 10dBi |
| Vertical Beamwidth | 8° |
| VSWR | ≤1.5 |
| Nominal Impedance | 50Ω |
| Polarization | vertical |
| Maximum Power | 100W |
| Dimensions | 1.8m |
| Weight | 2kg |
| Rated Wind Velocity | 60m/s |
| Connector | N Female or customization |
| Mounting Mast Diameter | Ø35~50mm |
Antenna Erection:
1 Fix the wave director and the oscillator in a counterpoint ( please take notice that the drain hole of oscillator should be downward).
2 Erect the antennas to the pole with clamp according to polarization required.
3 Connect the RF cables well, and wrap up the connector with waterproof adhesive tape, and do not let the cable flutter in the wind.
4 Make a shield for protection the water back into the home before RF cables were acrossed indoor.
